321 Titanium Stabilized Valve Castings

Product Name: 321 Ti-Stabilized Stainless Steel Valve Castings
(Shandong Hongyang Special Steel - High-Temperature Corrosion Solutions Specialist)

Precision-cast from ZG10Cr18Ni9Ti (321 Stainless Steel) with titanium stabilization, our valve components are engineered for high-temperature corrosive media. Ideal for acidic/oxidative environments up to 650°C with intergranular corrosion risks, delivering 2-3x longer service life than standard 304 valves.

1. Intergranular Corrosion Protection

Ti stabilization: Ti≥5×C content eliminates sensitization (ASTM A262 Practice E certified)

High-temperature strength: Maintains ≥150MPa yield strength at 600°C

Oxidation resistance: <0.2mm/year scale thickness at 900°C

2. Precision Casting Technology

Complex flow paths: Monobloc cast body/bonnet eliminates weld weaknesses

Dimensional control: CT6 tolerance (ISO 8062) on critical sealing surfaces

Surface quality: As-cast Ra≤12.5μm, machined finish to Ra1.6μm

3. Full-Spectrum Performance

Media compatibility: Resists mixed acids (≤40% H₂SO₄/HNO₃)

Pressure ratings: Class 150-2500 (ASME B16.34 compliant)

Cryogenic toughness: ≥80J impact at -196°C (LNG-proven)

Typical Applications

Refining: FCC unit hot valves (650°C/sour gas)

Chemical Plants: Nitric acid control valves (40% HNO₃ @90°C)

LNG Facilities: Cryogenic globe valves (-162°C service)

Nuclear Systems: Boric acid regulating valves (radiation-resistant)

✔ Composition control: Per-heat spectral analysis + Ti/C ratio verification
✔ NDT: 100% PT on bodies + 20% RT sampling
✔ Performance testing: Simulated operating condition P-T cycling

• API 600/API 6D • ASME B16.34 • NACE MR0175
• EN 10204 3.1 certification • PED 2014/68/EU

Optional Enhancements:

X-ray inspected castings (ASTM E186 reference)

Cryogenic impact testing reports

3D scanned dimensional reports

Engineering Support

• Material selection guidance for specific media
• CFD-optimized flow path designs available
• Prototype development within 20 working days
